Available with or without outer heat saving insulation covers. We make these heaters in S.S, Brass, MS, materials depending upon applications and requirement of actual users. Specially selected mica or micanite sheets and a specific gauge nickel-chrome resistance ribbon wire are used.
| Technical Specifications | |
| Sheath material | Stainless Steel 304 / Brass / M S Galvanised |
| Insulatation material | Mica & Micatile Sheet |
| Heating element | NiCr 80 : 20 |
| Connection leads | Fibre Glass Metal Braided Cable |
| Voltage | 110 to 440 volts |
| Surface Load | Upto 30 w / In2 |
| Power tolerance | / - 10% |
| Resistance | / - 10 % |
| Insulation resistance (Cold) | 20 M Ohms |
| Clamping gap | 8 to 10 mm |
| Sheath temperature | Upto 400ºC |
| Applications : | |
• |
Plastic processing Machinery |
• |
Injection and Blow Molding |
• |
Extruders |
• |
Many other Applications |
